8 Pin Inline Waterproof Connector IP67/IP68 25A Quick Lock for LED Lighting Equipment 0.75mm² 1.0mm² 1.5mm² 2.5mm²

The ACOHUA K25 Wire-to-Female Panel Waterproof Connector is engineered for harsh outdoor & industrial environments, offering reliable, dust-tight, and waterproof connections. With a quick-lock mechanism, it simplifies installation while ensuring 1000+ mating cycles. Ideal for LED lighting, solar systems, and outdoor equipment where moisture, dust, or vibration resistance is critical.

Dual Protection Rating: IP67/IP68 – Fully waterproof (submersible) and dust-tight, even in heavy rain or submerged conditions.

High Current & Voltage: Supports up to 35A (2-4 pins) / 20A (5 pins) and 300V for high-power applications.

Wide Wire Compatibility: Accepts wire gauges up to 4.0mm² (≤2.5mm² for mixed-core configurations) with cable OD 6.5–15mm.

Field Assembly Flexibility: Available in 3 connection types – Solder, Screw, or Quick Lock– for easy on-site installation.

Temperature Resistant: Operates in -40℃ ~ +105℃, suitable for extreme cold/hot environments.

Durable Design: Gold-plated contacts + rugged plastic housing ensure stable conductivity and long service life.

Customizable: Supports custom pin layouts (2-5 pins, including 2+3, 2+4, 2+5, 3+5 mixed cores).

• Outdoor LED Lighting (streetlights, floodlights, grow lights)
• Solar Power Systems (panel-to-inverter connections)
• Industrial Equipment (machinery, control boxes)
• Marine & RV Electrical Systems
• Agricultural & Horticultural Equipment

And there are also other PIN for you choose, like 4PIN/5PIN/6PIN..., check the wire gauge and the current and make a design, then we will help you to choose a solution according to the design.Thanks!
