Power Control System M20 Connector Panel Mount Male Plug Female Socket Screw Locking Cable Connector 3Pin Connector IP68-rated Connector for Lighting Wiring

M20  assembly waterproof connector can be combined with L/T/Y/F Type connectors to provide a solution for LED lamp modules.
Widely used in LED plant growth lamp, streetlight, garden light, stage light, LED outdoor display, junction box, outdoor engineering,
mining engineering, solar-wind power, solar water heaters and various machinery and so on..

If you need help,pls contact our team:

1.Screw wiring type assembly waterproof plug M20.
There are Solder Type and Screw type Wiring for your choice.
Connector coming without cable.  Operating tool:A well screwdriver.
It is composed of Male core,Female core,O-ring ,Housing, Seal Ring and Screw Nut.

How to order a suitable connector?

Before order, please specify the details of your cable as follow:
1. How much Voltage/Current do you need this connector to carry on?
 Such as: 300V 10A...

2.What's the Wire size do you need this connector to connect?
Such as: 3*1.5mm²...

3. What is the Cable outer diameter(OD)?
 Such as: 8.3mm,then we can select a suitable seal ring for connector.

A suitable size of the seal ring can help the connector achieve better waterproof effect,
according to the cable outer diameter to choose seal ring size.


Solder Type Wiring Terminal: 2PIN Wire to wire Male Female connector.

Male Front Panel Mount Part Number:
AH-M20-1502FMF01112
Female Part Number:
AH-M20-1502MFZ01112

1.Plastic Material: Nylon PA66.
2.Contact Material: Gold-plated Brass,Nickel-Plated Brass.
3.Voltage/Current: 300V 15A.
4.Mechanical Life: 3000 mating cycles.
5.Contact Conductor Diameter: 2.0mm
6.Connection Cable OD: 4.5~10mm.
7.Cable Gauge: 0.2mm2,0.3mm2,0.5mm2,0.75mm2,1.0mm2,1.5mm2;
24AWG,22AWG,20AWG,18AWG,16AWG.
8.Certificate: UL/TUV/CE/ROHS/ISO9001...
9.Major Market for Sales: All Over the World...

Solder Type Wiring Terminal: 3PIN Wire to wire Male Female connector.

Male Front Panel Mount Part Number:
AH-M20-1503FMF01112
Female Part Number:
AH-M20-1503MFZ01112

1.Plastic Material: Nylon PA66.
2.Contact Material: Gold-plated Brass,Nickel-Plated Brass.
3.Voltage/Current: 300V 15A.
4.Mechanical Life: 3000 mating cycles.
5.Contact Conductor Diameter: 2.0mm.
6.Connection Cable OD: 4.5~10mm.
7.Cable Gauge: 0.2mm2,0.3mm2,0.5mm2,0.75mm2,1.0mm2,1.5mm2;
24AWG,22AWG,20AWG,18AWG,16AWG.
8.Certificate: UL/TUV/CE/ROHS/ISO9001...
9.Major Market for Sales: All Over the World...



Screw Type Wiring Terminal:
2PIN Wire to wire Male Female connector.

Male Front Panel Mount Part Number:
AH-M20-1502FMF02122
Female Part Number:
AH-M20-1502MFZ02122

1.Plastic Material: Nylon PA66.
2.Contact Material: Gold-plated Brass,Nickel-Plated Brass.
3.Voltage/Current: 300V 5A.
4.Mechanical Life: 3000 mating cycles.
5.Contact Conductor Diameter: 2.0mm.
6.Connection Cable OD: 4.5~10mm.
7.Cable Gauge: 0.2mm2,0.3mm2,0.5mm2,0.75mm2,1.0mm2,1.5mm2;
24AWG,22AWG,20AWG,18AWG,16AWG.
8.Certificate: CE/ROHS/ISO9001...
9.Major Market for Sales: All Over the World...

AH-M20-1503FMF02122

There are Wire to Panel and pre-wired type connector to meet your needs.
