T Type Customized 3 Way Connector 3PIN Cable Conenctor IP68 Waterproof

Customized T Type Signal Electrical Cable Connector

Want to achieve multi-purpose cables, Want to save cable space,  Want to achieve multi-purpose cables and save space while also having excellent waterproofing? but feel stuck when trying to create them yourself? ...

Find us, you can be sure to have a solution you can trust.!

This is a customized T Type connector, 3-Way Connection Scheme Design.

1. Product Type
This is a multi-branch waterproof splitter (ring layout) designed to split a single power/signal line into multiple outputs, supplying power to several LED strips (or luminaires) while maintaining waterproof functionality.

2. Core Features
Structure: Main cable forms a loop, with branch cables featuring waterproof connectors (typically 2-pin/3-pin waterproof plugs);
Waterproof Rating: Generally achieves IP65/IP67, suitable for outdoor and damp environments in LED lighting applications (e.g., landscape lighting, LED strip chaining);
Applications: Commonly used in LED strips, decorative lighting, and outdoor illumination projects to centralise wiring for multiple fixtures.

3. Advantages
Eliminates the hassle of individual wiring connections, enabling power supply to multiple fixtures with a single connection;
Waterproof design prevents short circuits and leakage risks in outdoor/humid environments.

4.Product Specifications

1. In this conenctor, the wire gauge is 3PIN*0.5mm²
2. The connector we use is M12 3 PIN Connector
3. And each length of the cable is customized, it can support 300mm, 500mm,800mm...., this is customized according to the devies to the connectors.
