High-Power Air Conditioning Outdoor Waterproof Connection Plug 10A Screw Fixing Type

Among our range of connector products, there exists a connector suitable for applications with limited assembly space, requiring high current capacity.

In this type of connector, the male and female terminals are designed as a single integrated unit, making it a favourable option for those seeking to reduce design costs.

Current: 10A

Voltage Rating: 300V

Suitable Wire Gauge: ≤0.75mm²

1. Assembly Plug

AH-M15-1002Z01122                 AH-M15-1003Z01122

2.  Over Molded with Cable

AH-M15-1002X01123      AH-M15-1002X01123

If you don't know how to choose them, you can contact us freely. And we will geive you answer ASAP. Thanks!
