This is an AHUA brand waterproof connector, a commonly used accessory for outdoor electrical connections. Its main features and information are as follows:
1. Product Type
This is a waterproof male-female mating connector, the diagram includes:
- Cable-attached splitter connectors (such as the central "one-to-many" branching variant)
- Independent male and female connectors (including terminals and dust caps)
- Plug assemblies of various specifications (suitable for different cables/applications)
2. Core Functionality
Achieves IP68-rated waterproofing and dust resistance through a waterproof sealing design (such as the red rubber ring), enabling stable power/signal transmission in outdoor, damp, and dusty environments while preventing short circuits and electrical leakage risks.
3. Application Scenarios
Commonly found in:
LED outdoor luminaires (such as landscape lights, wall-washing lights)
Landscape/architectural illumination projects
Surveillance equipment, 5G base stations
New energy equipment, industrial automation and other scenarios requiring outdoor wiring
4. Product Advantages
Supports screw-clamp/solderless wiring for straightforward installation;
Covers multiple core counts (2 to 12 cores) and specifications (e.g., M16/M20 models) to accommodate varying power requirements;
Complies with CE, TUV and other certifications, ensuring high safety and durability.
